Simulator

How it works

Architecture overview. The simulator is a single Go binary (cmd/erpc-simulator/main.go) embedding all browser assets via //go:embed all:web. It binds one HTTP server on 127.0.0.1:8080 (configurable via -addr) serving static assets at / and a WebSocket endpoint at /ws. Behind the WebSocket lives an Orchestrator that owns the real *erpc.ERPC instance, a synthetic UpstreamHub HTTP server (on a random loopback port), and rolling stats counters. [internal/simulator/orchestrator.go:L51-95]

Traffic generation. Traffic generation is browser-side. The JavaScript runtime ticks at the configured RPS and for each tick builds a send-batch WebSocket frame. The backend's Session.execute goroutine calls Orchestrator.Execute(ctx, method, params) for each item, which calls net.Forward(rctx, req) — eRPC's real network handler. The full request path runs: selection policy → failsafe (retry/timeout/hedge/consensus) → HTTP transport to the fake upstream → response parsing. After Forward returns, Execute reads req.ExecState().UpstreamAttemptLog(), builds a TraceEvent, and queues it for the 50ms traces WebSocket push. [internal/simulator/orchestrator.go:L597-708]

UpstreamHub. A single http.Server multiplexed across N synthetic upstreams at paths /sim/<id>. Per request: (1) looks up UpstreamKnobs under RLock; (2) if Available=false, immediately returns HTTP 503; (3) rolls three thresholds in order — throttle rate (fast 429, no sleep), timeout rate (hang 30s after sleep), error rate (HTTP 500/502/503 or JSON-RPC -32000/-32603 in a 5-way split); (4) on success, calls synthResult to produce a plausible method-specific JSON-RPC response. Latency is sampled as max(1ms, base + |gaussian()| × jitter × 0.6). [internal/simulator/upstream_sim.go:L401-468]

Block model. Each upstream maintains an independent atomic.Int64 head, advanced by a single hub-wide goroutine ticking every 250ms. Per-upstream BlockTimeMs (default 12,000ms) controls step size. BlockLag is subtracted from head at response time. A hub-level hubHead tracks the maximum across all upstreams; new upstreams seed at 22_000_000 (plausible mainnet). Block timestamps use simGenesisUnix + block × 12s so the health tracker's block-time EMA converges correctly. [internal/simulator/upstream_sim.go:L135-177]

Data availability model. For sparse-data methods (eth_getTransactionReceipt, eth_getBlockByHash, eth_getLogs, eth_getTransactionByHash), a deterministic FNV-like hash of (upstreamID, method, params) determines whether the upstream "has" the data. Per-method baselines: receipt/tx 80%, block-by-hash 90%, getLogs 85%. The DataAvailability knob (0–1) multiplies the baseline; at exactly 1.0 it always returns data (bypasses baseline); at 0 it always misses. [internal/simulator/upstream_sim.go:L613-648]

Seed configuration. On first boot the orchestrator uses SeedYAML — eight upstreams (alc-eth-1, alc-eth-2, drpc-eth-1, quik-eth-1, chainstack-eth-1, conduit-eth-1, self-eth-1, public-eth-1) on network evm:1. scoreMetricsWindowSize: 10s and selectionPolicy.evalInterval: 1s are deliberately tighter than production so health dynamics are visible in seconds, not minutes. The browser's "↺ default" button restores this YAML. [internal/simulator/config.go:L12-22]

Config apply flow. When the browser sends apply-config, the YAML must have the {SELECTION_POLICY_FUNC} placeholder already substituted by the frontend. The backend: (1) DecodeConfigYAML — YAML decode + legacy migration, KnownFields(true) (typos are hard errors); (2) RewriteEndpoints — overwrites every upstream endpoint to http://<hubAddr>/sim/<id>, forces vendor type to evm; (3) FinalizeConfig — SetDefaults + Validate; (4) syncUpstreamKnobs — creates/refreshes/orphan-drops knob entries; (5) creates a fresh erpc.ERPC, bootstraps it, enables policy step log; (6) re-applies pause state. Previous eRPC instance is replaced atomically; in-flight requests against the old pointer complete normally. [internal/simulator/orchestrator.go:L251-298]

Selection policy live edit. apply-policy compiles the JS source via common.CompileProgram (sobek), injects the source into the stored YAML via injectPolicyIntoYAML, and re-boots. validate-policy compiles only — no apply. The frontend sends validate-policy on every debounced keystroke and apply-policy on explicit "Apply." The policy step log is always enabled (net.SetPolicyStepLogEnabled(true)) so the policy-history drawer shows the full per-step chain trail on every eval tick. [internal/simulator/orchestrator.go:L396-421]

Scenarios. Six built-in scripted scenarios automate upstream degradation without manual slider work, advancing via a 250ms scenarioLoop ticker:

• gradual-degradation (90s) — raises alc-eth-1 error rate 5% → 70%
• vendor-region-outage (60s) — makes Alchemy us-east region unavailable, then restores
• traffic-spike (60s) — degrades all upstream latency and error rates, then recovers
• hedge-saturator (60s) — increases jitter, then pins specific upstreams to high latency
• policy-exclude-cascade (50s) — pushes distinct failure modes onto three upstreams
• slow-network (60s) — triples latency and doubles jitter on all upstreams

Each scenario step calls the same Orchestrator.UpdateUpstream code path as manual slider changes. [internal/simulator/scenarios.go:L114-145]

Knob live tuning. Every synthetic upstream exposes UpstreamKnobs — latency, error rate, timeout rate, throttle rate, block lag, data availability, and a hard on/off toggle — changeable live via set-knob WebSocket messages without reloading the config. Default knob values are biased by tags: premium starts at base=35ms, error=0.003; tier:fallback starts at base=180ms, error=0.080, blockLag=4. The "inject 60s failure" button forces errorRate ≥ 0.9, timeoutRate ≥ 0.3 for 60 seconds via InjectFailureUntilMs.

Pause. SetPaused(true) stops Execute from forwarding requests (returns nil) AND pauses the policy engine's eval ticker via net.SetPolicyEnginePaused(true). This keeps position/score pills in the upstream panel stable while paused. Both flags re-sync when a config or policy apply lands mid-pause — the new engine starts un-paused and is immediately re-paused. [internal/simulator/orchestrator.go:L219-234] [internal/simulator/orchestrator.go:L289-296]

Dump file. Pass -dump-file path/to/run.jsonl to capture a JSONL forensic log. Every observable event is recorded: boot, config.snapshot, config.apply, policy.apply, knob.change, knob.inject, scenario.start, scenario.stop, scenario.event, paused, request, stats. The request event carries the full TraceEvent (per-attempt log, selection trail, outcome) plus raw params and JSON body. A companion *.AGENTS.md is written at open with field descriptions and idiomatic jq queries. Buffer is 64KB, flushed every 1s; a crash loses at most ~1s of trailing events. [internal/simulator/dump.go]

Rolling stats and WebSocket cadence. stats frames are sent every 200ms; traces are batched every 50ms with a cap of 256 items per flush. The session's outbound channel holds 256 frames; when full, frames are dropped silently — the UI is lossy by design. A 1-second bucket rolls every second; Stats() returns the previous second's completed bucket for the RPS display. Per-upstream latency percentiles (p50/p70/p90/p95) keep the last 300 samples. Policy scores and health tracker metrics are read live from the engine and tracker on every Stats() call — the simulator has no parallel bookkeeping for these. [internal/simulator/orchestrator.go:L804-970] [internal/simulator/ws.go:L19-64]

Config schema

The simulator accepts four CLI flags. Configuration of the eRPC instance is done through the browser YAML editor or apply-config WebSocket messages — there is no separate simulator config file.

UpstreamKnobs schema

All fields are live-tunable via set-knob WebSocket messages (UpstreamKnobPatch; pointer fields, nil = unchanged). Struct at internal/simulator/types.go:L47-77.

Default bias rules (internal/simulator/defaults.go):

• Tag premium: base=35, jitter=12, error=0.003
• Tag dedicated: base=45, jitter=18, error=0.005
• Tag tier:fallback: base=180, jitter=110, error=0.080, timeoutRate=0.020, throttleRate=0.040, blockLag=4
• Vendor self-hosted: base=28, jitter=12, error=0.02
• Vendor public (no fallback tag): error=0.08, base=180, jitter=110, blockLag=4

Worked examples

1. Reproduce a production failover chain offline. You want to confirm that when your primary drops, the retry/hedge combo still routes cleanly without thundering-herd. Set alc-eth-1 to available=false in the knob panel and watch the traces drawer. When you see selReason: "retry" or outcome: "hedge-win" for all requests, failover is working. Then start vendor-region-outage to let the scenario automate the degradation/restore cycle and verify score recovery:

start-scenario: vendor-region-outage
# watch policy-history frames: excluded[] should clear within ~10s of restore

2. Tune selection policy against bimodal data availability. You have premium and fallback upstreams with different data fill rates; you want your policy to prefer upstreams that actually have the data. Set dataAvailability=0.3 on fallback upstreams and dataAvailability=1.0 on premium. Run eth_getTransactionReceipt traffic and watch the traces frame — selReason: "sweep" on the first attempt means the policy fell back for a data miss. Adjust your policy's missRate weight until sweeps disappear from primary attempts.

3. Validate a new selection policy before deploying. Paste your policy JS into the policy editor, click Validate to compile-check, then Apply. Run the gradual-degradation scenario (90s) while watching the policy-history drawer — the steps[] chain shows exactly which upstream attribute triggered each position change. Compare score trajectories before and after to confirm the degrading upstream loses rank within your target latency window.

4. Offline forensic replay with -dump-file. Run a session that exercises a tricky edge case, then exit:

go run ./cmd/erpc-simulator -dump-file run.jsonl
# ... reproduce the issue ...
# Ctrl-C
jq 'select(.kind=="request" and .body.outcome=="fail")' run.jsonl | head -20
jq 'select(.kind=="request") | .body.attempts[] | select(.error != null)' run.jsonl

The *.AGENTS.md companion lists every queryable field and idiomatic jq recipes for slicing by outcome, upstream, and method.

Request/response behavior

WebSocket protocol — client → server frames:

{"kind":"hello"}
{"kind":"send-batch","items":[{"id":123,"method":"eth_blockNumber","params":[]}]}
{"kind":"send-one","req":{"id":123,"method":"eth_blockNumber","params":[]}}
{"kind":"set-knob","id":"alc-eth-1","patch":{"error":0.1,"base":200}}
{"kind":"apply-policy","src":"<JS source>"}
{"kind":"validate-policy","src":"<JS source>"}
{"kind":"apply-config","yaml":"<YAML with policy inlined>"}
{"kind":"validate-config","yaml":"<YAML>"}
{"kind":"set-paused","paused":true}
{"kind":"start-scenario","name":"gradual-degradation"}
{"kind":"stop-scenario"}

WebSocket protocol — server → client frames:

{"kind":"snapshot","body":{"yaml":"...","defaultYaml":"...","upstreams":[...],"policy":"...","defaultPolicy":"...","paused":false,"serverTimeMs":1234567890}}
{"kind":"stats","body":{"tick":...,"actualRps":...,"lastSecondTotal":...,"lastSecondSucc":...,"lastSecondErr":...,"lastSecondCache":...,"lastSecondRetryOk":...,"lastSecondHedge":...,"lastSecondMiss":...,"perUpstreamLastS":{...},"upstreams":{...},"policyLastSwitchMs":...,"scenario":...}}
{"kind":"traces","body":{"items":[...]}}
{"kind":"policy-history","body":{"items":[...]}}
{"kind":"policy-result","body":{"ok":true,"compiledAt":1234567890}}
{"kind":"policy-validate-result","body":{"ok":false,"error":"ReferenceError: x is not defined"}}
{"kind":"config-result","body":{"ok":true,"appliedAt":1234567890}}
{"kind":"config-validate-result","body":{"ok":false,"error":"yaml decode: ..."}}
{"kind":"knob-changed","body":{}}
{"kind":"error","body":{"msg":"unknown kind: foo"}}

TraceEvent.outcome values: "ok", "retry-ok", "hedge-win", "fail", "cache-hit". Source: internal/simulator/types.go:L107

TraceAttempt.selReason values: "primary", "retry", "hedge", "consensus_slot", "sweep". Source: internal/simulator/types.go:L165

StatsFrame.upstreams map values (UpstreamStatsRow): errorRate, throttleRate, misbehaviorRate from the health tracker; p50, p70, p90, p95 in ms; blockHeadLag, finalizationLag in blocks; blockHeadLagSeconds, finalizationLagSeconds (block count × tracker's EMA block-time in seconds); cordoned, cordonedReason; score from Engine.GetScores("*"); position (0 = primary, 1..N = fallback, -1 = excluded); selectionsLast (count in previous 1-second bucket).

PolicyDecisionFrame (in policy-history): id (slug formatted as <network>/<method>/<unix-ms>), steps[] (stdlib step chain — always populated in simulator, disabled in production), metrics (per-upstream metric snapshot the eval saw at that tick), perUpstreamScore (JS-produced scores from that tick), excluded[] (excluded upstreams with step and reason).

Outcome roll order (per request, first match wins). Source: internal/simulator/upstream_sim.go:L401-465

1. roll < throttleRate → HTTP 429 (no sleep)
2. Sleep max(1ms, base + |gaussian()| × jitter × 0.6)
3. (roll - throttleRate) < timeoutRate → hang 30s (simulates eRPC timeout)
4. (roll - throttleRate - timeoutRate) < errorRate → error (5-way mix: HTTP 500, 502, 503, JSON-RPC -32000, -32603)
5. Otherwise → success + synthResult

InjectedFailure override — active when InjectFailureUntilMs > 0 AND now.UnixMilli() < InjectFailureUntilMs. While active: errRate = max(errRate, 0.9), timeoutRate = max(timeoutRate, 0.3). Source: internal/simulator/types.go:L75-77

synthResult method coverage — the fake upstream returns plausible responses for:

• eth_blockNumber — hex(head - blockLag)
• eth_chainId — always "0x1" (see edge cases)
• net_version — "1"
• eth_syncing — false
• eth_getBalance — deterministic non-zero from params hash
• eth_getCode — synthetic non-empty bytecode
• eth_call — synthetic non-empty result
• eth_estimateGas — "0x5208" (21000)
• eth_gasPrice — "0x3b9aca00" (1 gwei)
• eth_getTransactionCount — deterministic 0–999 nonce
• eth_getBlockByNumber — block object with number/hash/parentHash/timestamp; null for blocks above head
• eth_getBlockByHash — 90% data availability baseline (scaled by knob)
• eth_getTransactionReceipt — 80% baseline (scaled by knob)
• eth_getTransactionByHash — 80% baseline (scaled by knob)
• eth_getLogs — 85% baseline; one synthetic log entry on hit, empty array on miss
• eth_feeHistory — minimal stub
• all others — "0x0"

Source: internal/simulator/upstream_sim.go:L481-608

Best practices

• Set scoreMetricsWindowSize and evalInterval back to production values before drawing conclusions about routing timing. The SeedYAML defaults (10s/1s) are deliberately fast for visibility — production typically uses 60s/5s.
• Use DataAvailability=1.0 on all upstreams when you only want to test routing/failsafe mechanics, not data-replication behavior. At 1.0, synthResult always returns data for every sparse method, eliminating sweep retries that would otherwise add noise.
• Pair -dump-file with every experiment where you intend to iterate offline. The JSONL log lets you replay and slice the attempt chain (jq '.body.attempts[]') without having to reproduce the exact scenario timing again.
• Override AttemptErrorDetailMaxLen=0 is already set by default in the simulator binary — don't re-add it. In production builds it is limited to prevent large error payloads; the simulator intentionally removes that cap to show the full chain.
• Use -log-level debug when a scenario produces unexpected outcomes not explained by the traces drawer — the in-process eRPC instance logs upstream selection and failsafe decisions at debug level.
• -web-dir accelerates policy development. Point it at cmd/erpc-simulator/web/ and save your JSX changes — the browser hard-reload picks them up instantly without a Go rebuild, making the edit–apply–observe loop faster.
• Run the simulator's seed_boot_test.go after modifying the SeedYAML or default policy — it verifies the init() expansion, the absence of the placeholder literal, and that the full eRPC stack bootstraps cleanly.

Edge cases & gotchas

1. {SELECTION_POLICY_FUNC} must be substituted by the browser before apply-config. The backend has a safety net (expandPolicyPlaceholder) that substitutes the default policy if the placeholder leaks through a direct API call, but the browser is the authoritative substitution site. Source: internal/simulator/config.go:L148-153, internal/simulator/orchestrator.go:L153
2. eth_chainId always returns "0x1" regardless of configured chainId. This is a known simplification; the SeedYAML uses chainId: 1 (Ethereum mainnet) to match. Source: internal/simulator/upstream_sim.go:L489
3. Batch upstream request: first transport error aborts the whole batch. A 429 or 5xx on one item fails the entire batch transport — matching real HTTP behavior. Source: internal/simulator/upstream_sim.go:L358-364
4. Orphan knob cleanup on apply-config. When an upstream is removed from the YAML, its knob and rolling stats entry are permanently dropped. Manually-tuned values for that upstream are lost on config reload. Source: internal/simulator/orchestrator.go:L333-341
5. -dump-file is append-only. Restarts accumulate multiple boot events. Use jq 'select(.kind=="boot")' to find session boundaries, then bound queries with the most recent boot timestamp.
6. DataAvailability = 1.0 bypasses per-method baselines. At exactly 1.0, scaleAvailability returns 100 regardless of the method's natural miss rate. Source: internal/simulator/upstream_sim.go:L635-638
7. All cached assets are no-store. Every page load re-fetches all JSX/CSS. This prevents stale-asset bugs during development but adds ~100ms to initial load time. Source: cmd/erpc-simulator/main.go:L188-193
8. Per-request context timeout is 30s — a hard cap in Execute independent of eRPC's failsafe timeout config. Source: internal/simulator/orchestrator.go:L617
9. Response body preview cap is 8KB with truncation markers "\n…[truncated]…\n" when exceeded. Source: internal/simulator/orchestrator.go:L713-729
10. scoreMetricsWindowSize: 10s and evalInterval: 1s in SeedYAML are intentionally tighter than production defaults — they make health score dynamics visible in seconds. Override them in your YAML if you need production-realistic timing. Source: internal/simulator/config.go:L43-196
11. Legacy config migration is wired — the simulator accepts old-style YAML without errors, the same as the production binary. Source: cmd/erpc-simulator/main.go:L73
12. AttemptErrorDetailMaxLen is set to 0 (unlimited) so the lifecycle drawer shows the full per-attempt error chain. Production binaries truncate this. Source: cmd/erpc-simulator/main.go:L79
13. Step log overhead. net.SetPolicyStepLogEnabled(true) is called at every boot. Production has this off by default; the always-on step trail makes policy evals in the simulator slightly heavier than production. Source: internal/simulator/orchestrator.go:L287
14. Static delay min/max are ignored. If you paste a hedge config with quantile=0 (static mode) and also set min/max, those bounds are silently ignored — Resolve returns base unchanged.
15. DecodeConfigYAML uses KnownFields(true). Any unrecognized YAML key is a hard decode error — typos in the YAML editor fail immediately rather than being silently ignored. Source: internal/simulator/config.go:L208
16. upstream_sim.go uses math/rand, not crypto/rand, for all simulation randomness (throttle/timeout/error dispatch, Box-Muller sampling). This is intentional for statistical sampling; #nosec G404 annotations in the source acknowledge the deliberate choice. Source: internal/simulator/upstream_sim.go:L415
17. Policy engine pause state re-applied after every config/policy apply. Because a fresh *erpc.Network is created each time, the new engine starts running by default. Without re-applying pause, the UI would show drifting policy decisions while the simulator is paused. Source: internal/simulator/orchestrator.go:L289-296
18. SeedYAML const retains {SELECTION_POLICY_FUNC} placeholder by design. This is what the snapshot frame returns as defaultYaml for the browser's "↺ default" button (the frontend shows the templated view). Only SeedYAMLExpanded has the placeholder substituted; this is validated in seed_boot_test.go:TestSeedYAMLExpanded_IsValid.
19. WebSocket read limit is 8MB per message. Messages larger than 8MB are rejected. Source: internal/simulator/ws.go:L53

Observability

The simulator does NOT export Prometheus metrics. Observability surfaces are:

Source code entry points

• cmd/erpc-simulator/main.go:L73-L99 (opens in a new tab) — entry point: CLI flags, legacy migration wiring, AttemptErrorDetailMaxLen, HTTP server setup, 5s shutdown grace
• internal/simulator/orchestrator.go:L51-L95 (opens in a new tab) — Orchestrator struct: owns *erpc.ERPC, UpstreamHub, rolling stats counters
• internal/simulator/orchestrator.go:L251-L298 (opens in a new tab) — ApplyConfig: decode → rewrite endpoints → finalize → sync knobs → bootstrap fresh ERPC → re-apply pause
• internal/simulator/orchestrator.go:L597-L708 (opens in a new tab) — Execute: calls net.Forward, reads UpstreamAttemptLog, builds TraceEvent
• internal/simulator/upstream_sim.go:L401-L468 (opens in a new tab) — outcome roll: throttle → sleep → timeout → error → success + synthResult
• internal/simulator/upstream_sim.go:L481-L608 (opens in a new tab) — synthResult: method-specific response generation for all supported EVM methods
• internal/simulator/upstream_sim.go:L135-L177 (opens in a new tab) — block advancement ticker: 250ms hub loop, per-upstream BlockTimeMs
• internal/simulator/ws.go:L19-L64 (opens in a new tab) — Session WebSocket handler: stats/trace/policy-history tickers, outbound channel
• internal/simulator/config.go:L12-L22 (opens in a new tab) — SeedYAML const and init() expansion to SeedYAMLExpanded
• internal/simulator/scenarios.go:L114-L145 (opens in a new tab) — scenario advanceScenario: 250ms ticker, at-or-after step dispatch
• internal/simulator/dump.go (opens in a new tab) — Dumper: JSONL event recorder, 64KB buffer, 1s flush loop, *.AGENTS.md companion template
• internal/simulator/yaml_patch.go (opens in a new tab) — injectPolicyIntoYAML, expandPolicyPlaceholder
• internal/simulator/seed_boot_test.go (opens in a new tab) — TestSeedYAMLExpanded_IsValid: verifies init() expansion, placeholder absent, default policy body present, comments survive
